| SENSOR SECTION | Image Sensor | 1/2.5-type BSI MOS Sensor | |
|---|---|---|---|
| Total Pixels | 8.57 megapixels | ||
| Effective Pixels | Motion Image | 4K: 8.29 megapixels [16:9], Full-HD: 6.17 megapixels [16:9] | |
| Still Image | 8.29 megapixels [16:9] 6.22 megapixels [4:3] |
||
| LENS SECTION | F Value | F1.8 (WIDE) / F4.0 (TELE) | |
| Optical Zoom | 24x | ||
| Focal Length | 4.12 – 98.9 mm (Optical Zoom:24x) | ||
| Filter Diameter | 62 mm | ||
| Lens Brand | Panasonic Lens | ||
| 35 mm Film Camera Equivalent | Motion Image (16:9) | 4K25p, 24p/Full-HD 24p: 25 – 600 mm, Full-HD 50p/50i/25p: 28.9 – 693.7 mm | |
| Still Image | 25.0mm – 600mm (16:9) / 30.6mm – 734.4mm (4:3) | ||
| CAMERA SECTION | Standard Illumination | 1400 lx | |
| Minimum Illumination | 1.5 lx (Scene Mode Low Light 1/25), 0.5 lx (Night Mode (Color)) | ||
| Focus | Auto / Manual | ||
| White Balance | Auto / White Set / Sunny / Cloudy / Indoor1 / Indoor2 | ||
| Iris | Auto / Manual | ||
| Image Stabilizer | 5-axis HYBRID O.I.S.+ with Active Mode, Ball O.I.S. | ||
| Active Contrast | Yes | ||
| HDR Movie (Except 4K Mode) | Yes | ||
| Creative Control (Except 4K Mode) | Miniature Effect, Silent Movie, 8mm Movie, Time Lapse Rec | ||
| Zoom | Intelligent Zoom OFF | 24x | |
| Intelligent Zoom ON | 4K: 32x, Full-HD: 48x | ||
| Digital Zoom | 70x / 1500x (The maximum value of zoom magnification can be set in two patterns) | ||
| Shutter Speed | Motion Image | Auto Slow Shutter ON : 1/25 – 1/8000 (50p / 50i / 25p), 1/24 – 1/8000 (24p) Auto Slow Shutter OFF: 1/50 – 1/8000 (50p / 50i / 25p), 1/48 – 1/8000 (24p) |
|
| Still Image | 1/2 – 1/2000 | ||
| RECORDING SECTION | Recording Media | SD/SDHC/SDXC Memory Card | |
| Recording Format | [AVCHD] AVCHD Progressive [MP4] MP4 |
||
| Compression Method | MPEG-4 AVC/H.264 | ||
| Actual Recordable Time with Supplied Battery | Approx. 50 min (4K MP4) Approx. 55 min (50p mode) Approx. 1 h 0 min (PH mode) Approx. 1 h 0 min (HA mode) Approx. 1 h 0 min (HG mode) Approx. 1 h 0 min (HE mode) Approx. 50 min (2160p/24p) Approx. 55 min (1080p/24p) Approx. 55 min (MP4 50M) Approx. 55 min (MP4 28M) Approx. 1 h 10 min (MP4 720p) |
||
| Thumbnail Display | 6 thumbnails/page, 1 thumbnail/page | ||
| Audio Recording System | AVCHD: Dolby Audio (5.1ch / 2ch) MP4: AAC (2ch) |
||
| Microphone | 5.1ch Surround, Zoom, Focus and Stereo Microphone | ||
| Speaker | Dynamic type | ||
| Recording/ Playback Mode | AVCHD | 1080/50p (28Mbps / VBR), (1920 x 1080/50p) PH (24Mbps / VBR), (1920 x 1080/50i) HA (17Mbps / VBR), (1920 x 1080/50i) HG (13Mbps / VBR), (1920 x 1080/50i) HE (5Mbps / VBR), (1920 x 1080/50i) |
|
| MP4 | 2160/25p(72M) (72Mbps / VBR), (3840 x 2160) 2160/24p(72M) (72Mbps / VBR), (3840 x 2160) 1080/50p(50M) (50Mbps / VBR), (1920 x 1080) 1080/50p(28M) (28Mbps / VBR), (1920 x 1080) 1080/24p(50M) (50Mbps / VBR), (1920 x 1080) 720/25p(9M) (9Mbps / VBR), (1280 x 720) |
||
| iFrame | – | ||
| STILL IMAGE SECTION | Recording Format | JPEG (DCF/Exif2.2) | |
| Flash | – | ||
| Recording Image Size | Still Image | [16:9] 25.9megapixels (6784 x 3816), 14 megapixels (4992 x 2808), 2.1 megapixels (1920 x 1080) [4:3] 20.4 megapixels (5216 x 3912), 10.9 megapixels (3808 x 2856), 0.3 megapixels (640 x 480) |
|
| Simultaneous Recording | Full-HD only: [16:9] 14.0 megapixels (4992 x 2808), 2.1 megapixels (1920 x 1080) | ||
| GENERAL SECTION | Power Supply | 3.6V (Battery) / 5.0V (AC Adaptor) | |
| Power Consumption | Max. 5.4W (Recording) / Max. 7.7W (Charging) | ||
| Dimensions (W x H x D) | Approx. 68 x 77 x 141 mm (2.677 x 3.031 x 5.551 inch) | ||
| Weight (w/o battery and SD card) | Approx. 431 g (0.950 lb) | ||
| LCD Monitor | 7.5cm (3.0-inch) LCD monitor (1,843,200 dots), video display area (16:9):1,555,200dots | ||
| Touch Panel | Electrostatic | ||
| View Finder | – | ||
| Manual Ring / Dial | – | ||
| LED Video Light | – | ||
| Accessory Shoe | Yes (cold) | ||
| Lens Cover | Yes (Auto) | ||
| On-Screen Display Language | English, German, French, Italian, Spanish, Polish, Czech, Netherlandic, Turkish, Chinese Traditional, Russian, Arabian, Thai, Hindi, Hungarian, Ukrainian, Romanian | ||
| Interface | AV | – | |
| HDMI | Yes (micro) | ||
| Microphone (stereo mini) | Yes | ||
| LINE-IN (stereo mini) | Yes | ||
| Headphone (stereo mini) | Yes | ||
| Remote (super mini) | Yes | ||
| USB | USB Type-C, 2.0 Hi-Speed | ||
| USB Charge | Yes | ||
| Wi-Fi | Standard | – | |
| Frequency | – | ||
| NFC | – | ||
| STANDARD ACCESSORY | AC Adaptor | – | |
| AC Cable | – | ||
| DC Cable | – | ||
| Rechargeable Battery Pack | Yes (1,940mAh) | ||
| Battery Charger | – | ||
| IR Remote | – | ||
| HDMI Cable | Yes (micro) | ||
| AV Multi Cable | – | ||
| AV Cable | – | ||
| Shoe adaptor | – (Built-in) | ||
| Lens Hood | Yes | ||
| USB Cable | Yes | ||
| Editing Software | HD Writer AE 5.4 (Download) | ||
